High-Performance SBCs

ADL Embedded Solutions SBCs feature a broad range of Intel® processors from the latest, high-performance Intel Core i7 CPU architecture. COTS base models are fully featured with MCOTS variations available for any model.

Request A Quote

High-Performance Items & Descriptions

Item Code Description
ADLQ170HDS
  • 6th Generation Intel Core i3 / i5 / i7
  • Intel Q170 Chipset
  • Up to 32GB DDR43-2133
  • TPM 2.0
  • MTF > 300,000 hours
  • 4x PCie X1 Expansion Lanes
  • Standard -20C to +70C, -40C to +85C Option
ADLQM67PC-3517UE
  • Gen3 Intel® Core™ i7-3517UE, 1.7 GHz (Turbo up to 2.80 GHz)
  • Up to 8GB DDR3-1066/1333 DRAM SoDIMM204
  • Type 1 Bottom-Stacking PCIe/104 V2.01 with Gen2 Protocol (2.5 to 5 GT/s)
  • 2x SATA 600 Ports with RAID
  • 2x 10/100/1000 Mbit Ethernet LAN Port
  • 2x RS232 COM Ports, 8x USB2.0 Ports
  • Standard -25C to +70C, -40C to +85C Option
ADLQM87PC
  • Intel® Core™ i7 Dual/Quad, 1.6 GHz to 2.4 GHz
  • Intel® 8-Series PCH Lynx Point QM87 Chipset
  • Up to 8GB DDR3L-1600 DRAM
  • Type 1 Bottom-Stacking PCIe/104
  • 2x 10/100/1000 Mbit LAN
  • Video – VGA/DVI/HDMI/DisplayPort/eDP
  • Standard -25C to +70C, -40C to +85C Option
ADLQM67PC-2715QE
  • Intel® Core™ i7 Gen2 Quad 2.1GHz – 3GHz
  • Intel® QM67 PCH
  • Up to 8GB DDR3-1333 DRAM SoDIMM204
  • Type 1 Bottom-Stacking PCIe/104 V2.01 with Gen2 protocol (2.5 to 5 GT/s)
  • 2x SATA 600 Ports with RAID
  • 2x 10/100/1000 Mbit Ethernet LAN Port
  • Standard -25C to +70C, -40C to +85C Option
ADLQM67PC-827E
  • Intel® Celeron 827E, 1.4GHz based on Intel Core Technology
  • Up to 8GB DDR3-1333 DRAM SoDIMM204
  • Type 1 Bottom-Stacking PCIe/104 V2.01 with Gen2 protocol (2.5 to 5 GT/s)
  • 2x SATA 600 Ports with RAID
  • 2x 10/100/1000 Mbit Ethernet LAN Port
  • 2x RS232 COM Ports, 8x USB2.0 Ports
  • Standard -25C to +70C, -40C to +85C Option
ADLQM67PC-2655LE
  • Intel® Core™ i7, 2.2 GHz
  • Up to 8GB DDR3-1333 DRAM SoDIMM204
  • Type 1 Bottom-Stacking PCIe/104 V2.01 with Gen2 protocol (2.5 to 5 GT/s)
  • 2x SATA 600 Ports with RAID
  • 2x 10/100/1000 Mbit Ethernet LAN Port
  • 2x RS232 COM Ports, 8x USB2.0 Ports
  • Separate Onboard VGA, LVDS, HDMI / DVI, Display Port
ADLGS45PC
  • Intel® Celeron® M / Core™ 2 Duo (SFF), 1.2 GHz to 2.26 GHz
  • Intel® GS45 / ICH9M-E Chipset
  • Up to 4GB DDR3-1066 DRAM
  • Type 1 Bottom-Stacking PCI/104-Express
  • 2x 10/100/1000 Mbit LAN
  • Video – VGA/LVDS
  • Standard -25C to +70C, -40C to +85C Option
ADL945PC
  • Intel® Core™2 Duo / Core™Duo / Core™Solo, 1.0 GHz – 2.16 GHz
  • Intel® 945GME / ICH7 Chipset
  • Up to 2GB DDR2-667 DRAM
  • Bottom-Stacking PCI/104
  • 1x 10/100 Mbit LAN, 1x 10/100/1000 Mbit LAN
  • Video – VGA/LVDS
  • Standard -25C to +70C, -40C to +85C Option
ADL855PC
  • Intel® Pentium® M / Celeron® M, 0.6 GHz – 1.8 GHz
  • Intel® 855GME / ICH4 Chipset
  • Up to 1GB DDR-333 DRAM
  • Bottom-Stacking PC/104- Plus
  • 1x 10/100 Mbit LAN
  • Video – VGA/LVDS
  • Standard -25C to +70C, -40C to +85C Option
ADLGS45HDS
  • Intel® PGA478 Celeron® / Core™ 2 Duo / Core™ 2 Quad
  • Intel® GS45 / ICH9M-E Chipset
  • Up to 8GB DDR3-1066MHz DRAM
  • 2x 10/100/1000Mbit LAN Controllers
  • DVI Interface Onboard
  • 4x SATA 3Gb/s with RAID 0/1/5/10 Support
  • 8x USB2.0 Ports, 4x RS232 Ports
ADLQM87HD
  • Supports 4th Generation Intel® Core™ i7/i5 Quad/Dual
  • Intel PCH Lynx Point QM87
  • Up to 2x 8GB DDR3L-1600 DRAM
  • 2x 10/100/1000 Mbit LAN
  • 1x DVI-I (can be adapted to VGA/HDMI)
  • 1x I-PEX MiniCoax for DVI/HDMI/DP
  • Standard -25C to +70C, -40C to +85C Option
ADL3GQM67HDS
  • Intel® PGA478 Celeron® / Core™ 2 Duo / Core™ 2 Quad
  • Intel® GS45 / ICH9M-E Chipset
  • Up to 8GB DDR3-1066MHz DRAM
  • 2x 10/100/1000Mbit LAN Controllers
  • DVI Interface Onboard
  • 4x SATA 3Gb/s with RAID 0/1/5/10 Support
  • 8x USB2.0 Ports, 4x RS232 Ports
ADLQM67HDS
  • Supports 2nd Generation Intel® Core™ i7/i5 Quad/Dual
  • rPGA988B Socket; Intel QM67 PCH
  • Up to 2x 8GB DDR3-1333 DRAM
  • 2x 10/100/1000 Mbit LAN
  • 1x DVI-I (can be adapted to VGA/HDMI)
  • 1x I-PEX MiniCoax for DVI/HDMI/DP
  • Standard -25C to +70C, -40C to +85C Option
